Here is the photo album for Trevor Quarry, Penmaenmawr No. 'Redstone', a 0-4-0VBT located in Aberystwyth, Ceredigion. If you would like to suggest additional photos for this album, please click here.

Looking from the side of the loco shows that the two axles are driven via the coupling rod shown here.

The boiler, showing the pressure gauge the water level gauge and the connection for the whistle.

More detail on this vertical boilered design showing the general arrangement with the water tank on the left, the two vertical cylinders and the boiler.

Detail of the two vertical cylinders, back to back with their valve chests outside the cylinders. Looking further down gives a glimpse of the crank axle for the right hand cylinder in the photo.

Looking closer shows crank axle and connecting rod for the right hand cylinder with the eccentrics for the valve gear to the right.


Trevor Quarry, Penmaenmawr 0-4-0VBT No. 'Redstone' Aberystwyth, Ceredigion, UK	Location: Vale of Rheidol Railway Status: Display
